5 TECHNICAL SPECIFICATION.
MAINS SUPPLY
Marked: MAINS
Input voltage: 100 – 240 V DC / AC 50/60 Hz
Max power: 50W
Connector type: IEC Inlet Filter
Fuses: 2
Fuse type: 5x20mm
Fuse rating: T3.15A
INTERNAL BATTERY
Quantity: 1
Used for: Static and Dynamic Resistance measurement
Battery type: Hawker Lead Accumulator 6 V 5 A, 0809-0012 (XMB)
Battery rating 12Volt (2x6V 5A Lead accumulator)
Battery charging: 13.5-14.0V @ 0.5A
Battery float voltage: 13.6V @ 25°C
Life Time: <= 8 year
Fuses: 1
Fuse Panel mounted: BUSSMANN BY EATON 25A aM
MAIN CONTACTS
Marked: A1, A2, A3, A4, B1, B2, B3, B4, C1, C2, C3, C4.
Inputs: 12 independent.
Function: Measure contact timing of main and pre-insert resistor contacts
Voltage: 48Vdc
Current: Max 11 mA when load is between 24-48V
Max 30 mA when load is between 0-24V
Timing resolution: 20s at 50 KHz sampling.
Max Voltage between red and black output: 250VAC / 300VDC
AUXILIARY CONTACTS
Marked: 1a, 1b, 2a, 2b, 3a, 3b.
Inputs: 6 independent
Function: Measure contact timing of aux contacts
Voltage: 24Vdc
Current: Max 11 mA
Timing resolution: 20s at 50 KHz sampling.
Max Voltage between red and black output: 250VAC / 300VDC
TRAVEL INPUTS
Marked: T1, T2, T3.
Inputs: 3 digital or analog.
Digital input receiver: 2 RS422 quadrature inputs
Analog min resistance: 100 ohm.
Voltage measure: 5 V DC, accuracy 0,005V DC
Analog resolution: 14 bits. Resolution ≈ 0.6mV / Bit
Power output: +5 VDC 100 mA.
