COMMUNICATION INTERFACE 1
Marked: RS-232.
Protection: Internal isolated
Baud rate 115.2 K baud
Data size 8-bit
Parity None
Stop bits 1
Flow control none
COMMUNICATION INTERFACE 2
Marked: USB 1.1 / USB 2.0 full-speed.
Protection: Internal isolated
Baud rate 115.2 K baud
Data size 8-bit
Parity None
Stop bits 1
Flow control none
DISPLAY
Type: LCD Backlit
Characters: 4 rows, 20 characters per row. 5x8 Dots Per Character
PUSHBUTTONS
Marked: CLOSE, OPEN
Close button: Make a Close operation if breaker is in Open position
Open button: Make an Open operation if breaker is in Close position
Close + Open button: Make a Close-Open operation if breaker is in Open position
INTERNAL SAMPLING Max time @ 10 Hz 52428.799 seconds
Max time @ 100 Hz 5242.879 seconds
Max time @ 250 Hz 2097.151 seconds
Max time @ 500 Hz 1048.575 seconds
Max time @ 1000 Hz 524.287 seconds
Max time @ 2500 Hz 209.714 seconds
Max time @ 5000 Hz 104.857 seconds
Max time @ 10000 Hz 52,428 seconds
Max time @ 25000 Hz 20.971 seconds
Max time @ 50000 Hz 10.485 seconds
DIMENSION AND WEIGHT: Dimensions 458*331*153 (With*Height*Depth)
Weight about 1.2 kg
ENVIRONMENT: Operating temperature -20 - 40 °C
Storing temperature -40 - 40 °C
Transport temperature: -40 - 40 °C
Relative humidity 20 - 85% non-condensing
Altitude operating 2 000 m
Altitude non-operating 12 000 m
OVERVOLTAGE CATEGORY: II
MANUFACTURER: Elcon AB
Hyttrisvägen 27
770 14 Nyhammar SWEDEN
