Control Panel Reference (For details, refer to page numbers shown in parentheses)
Power ON/OFF: Hold both the RATE and A/B switches for 2 seconds (see “ON” label below the VFO A knob).
Tap / Hold Functions, e.g. PRE / NR: Tap to use the function labeled on or above a control; hold ½-sec for the function labeled below it.
Numeric Keypad: Twelve of the switches and knobs form a keypad (0-9/decimal/enter) for use with FREQ, etc.
Receive Transmit VFO A / Band / Mode VFO B / Misc.
AF/MON AF gain (17);
KYR- SPT /MIC DATA Data mode (27) MODE CW/SSB (15)
OFS/B Coarse VFO
tone/monitor level (17) Keyer (19); Spot (21); Mic gain (19) TEXT Text decode (29) RCL/SCN F. recall tuning (16);VFO B (16)
NB Noise blanker (18) PWR Power level (19) MSG Msg play (19, 30) (24), Scanning (24) CLR Clear RIT (16)
PRE Preamp / attenuator (17) ATU ATU tune (19) REC Msg record (19, 30) BAND Band (15) RIT Receive offset (16)
NR Noise reduction (18) PFn Prog. switch functions (25) RATE VFO tuning (16); STORE F. store (24) SPLIT Split RX/TX (30)
FIL / APF- AN Filtering XMIT TX/PTT (19) ON/OFF (with A/B) A / B A/B swap (16) DISP Special disp. (23)
(17); APF (18); auto-notch (18) TUNE CW carrier (19) FREQ Freq. entry (15) A > B A>B copy (16) MENU Menu (14)
