CTC-1132 868AM 2007.07.18
17
<
<
N
N
O
O
T
T
E
E
>
>
) The categories of devices are listed as
followings:
9 Door Contact ---- DC
9 Panic Button-PB
9 PIR Sensor ----- IR
9 Remote Controller --- RC
9 Remote Keypad ---KP
9 Smoke Detector --- SD
9 Water Sensor --- WS
9 Outdoor Siren --- BX
9 Universal Receiver – UR
9 Wireless Siren ---SR
Step 4. Press “OK” to confirm the device type.
A prompting message will be
displayed for 2 sec. to prompt you to
select the zone number for the device.
S e L e c t D e v i c e
Z o n e
Step 5. Then all the available unused zones
(zones which have no device added in)
out of a total 20 zones will be
displayed on the screen.
Z o n e 0 1
Z o n e 0 2
Z o n e 0 3
-
-
-
-
Z o n e 1 9
Z o n e 2 0
S T O P
Step 6. Use “S” & “T” keys to move the
cursor to the desired zone number
then press “OK”.
<
<
N
N
O
O
T
T
E
E
>
>
) When a sensor is added to the system
for the second time (without removing
first). An error message will be
displayed.
A l r e a d y E x i s t
i n s y s t e m
The message will be displayed for 2
sec. then the screen return to Step 1.
screen to wait for the signal from
another device.
) Pressing “ “ key will abort the
procedure and will not learn-in the
device.
) Depending the type of the device,
different screens will then be
displayed accordingly for further
configuration purpose.
Door Contact
StepA7. After a zone number for the Door
Contact is assigned, you can futher
specify how it will work in different
modes. You are requested to make a
selection among “Burglar”, “ Home
Omit”, “Home Access”, “Delay”,
“Entry”, “Away Only”, “24 Hour”,
“Fire”, “Medical Emg” and “Water”
device.:
Burgl a r
H o me O mi t
H o m e A c c e s s
DelaY
EntrY
24 Ho u r
Fire
M e d i c a l E
at er
<
<
N
N
O
O
T
T
E
E
>
>
) “B” for Burglar Door Contact
z When the system is in Arm mode, if a
“Burglar” Door Contact is triggered, a
“Burglar Alarm” will be activated
immediately and be reported.
z When the system is in Armed mode,
and the Control Panel is counting
down the Entry Delay, if a “Burglar”
Door Contact is triggered, the Control
Panel will not respond.
z During the Exit Delay period, if a
“Burglar” Door Contact is triggered,
the Control Panel will not respond .
) “O” for Home Omit Door Contact
z When the system is in Home mode, if
a “Home Omit” Door Contact is
triggered, the Control Panel will not
To Next Page
