CTC-1132 868AM 2007.07.18
18
respond.
z When the system is in Full Arm mode,
if a “Home Omit” Door Contact is
triggered, the Control Panel will
respond in the same way as if a
“Burglar” Door Contact is triggered.
) “A” for Home Access Door Contact
z When the Door Contact has been set
to “Home Access” and triggered
when the system is in Arm mode, the
Control Panel will start a Burglar
Alarm and be reported.
z When the system is in Home mode, if
a “Home Access” Door Contact is
triggered, the Control Panel will start
an Entry Delay period to give enough
time to disarm the system
z However, during the Entry Delay or
Exit Delay period, if a “Home Access”
Door Contact is triggered, the Control
Panel will not respond.
) “D” for Delay Door Contact
z When the system is in Arm mode, if a
“Delay” Door Contact is triggered first,
a “Burglar Alarm” will be generated
immediately.
z However, during the Entry Delay or
Exit Delay period, if a “Delay” Door
Contact is triggered, the Control Panel
does not respond.
) “E” for Entry Door Contact
z If the Door Contact has been set to
“Entry” and triggered when the
system is in Arm mode, the Control
Panel will start an entry period to give
enough time to disarm the system.
z After the delay period has expired and
no correct PIN code entered, the
Control Panel will respond with a
“Burglar Alarm” and be reported.
z If the Door Contact has been set to
“Entry” and triggered when the
system is in Disarmed mode, the
Control Panel will make a “ding-dong”
Door Chime sound (if programmed).
) “H” for 24 Hour Door Contact
z The“24 Hour” Door Contact is active
all the time and does not have to be
armed or disarmed.
) “F” for Fire Door Contact
z The “Fire” Door Contact is active all
the time and does not have to be
armed or disarmed.
) “M” for Medical Emgenercy Door
Contact
z A “Medical Emg” Door Contact is
active all the time and does not have
to be armed or disarmed.
) “W” for Water Door Contact
z “Water” Door Contact acts as an
Universal Transmitter and have a
Water leakage sensor connected to it.
z The “Water” Door Contact is active all
the time and does not have to be
armed or disarmed.
StepA8.Use the “T”,”S” to make your
selection and confirm by pressing
“OK”. You are now invited to give a
name or location description to the
device to help understand system
events. You can enter up to 10 letters
as you want for the name followed by
“OK” or just press “OK” for no name.
Please see section “Device Naming”
for details.
Ent er N a me + Ok
....... . . . . .
StepA9. Press “OK” when zone name entering
is completed. The display will show
the new zone name with the attribute
next to the device and prompt you to
confirm your programming:
I nst al l e d : ( OK?)
D C B a c k d o o r B
StepA10. Press “OK”, adding a Door Contact
is now completed, screen returns to
the “Device +/-“ menu.
<
<
N
N
O
O
T
T
E
E
>
>
) Press “ “, all the learning/setting
processes having done will be ignored,
the screen returns to “Device +/-
“ menu.
