CTC-1132 868AM 2007.07.18
34
enclosure from either being opened
or being removed from the mounting
surface.
z Sensor Low battery
If the battery voltage of PIR sensor, Door
Contact, Remote Keypad, Water Sensor,
Remote Controller or Smoke Sensor is
low, a “Sensor Low Battery” message will
be detected.
z Sensor out-of-order
After installation of the PIR sensor, Door
Contact, Water Sensor or Smoke Sensor,
a periodic supervision signal will be
transmitted at intervals between 60 min.
to 100 min.
If the Control Panel did not receive the
signals transmitted from any individual
sensor for a period of preset supervision
timer Hours Hours, a “sensor out-of-
order” fault event will be detected and
displayed.
z Interference
CTC-1132 can detect interference on both
433 Mhz and 868 Mhz frequency band.
After a continuous interference signal is
present for more than 30 seconds, an
interference event can be logged,
reported and displayed on the LCD (if
Fault Display submenu is chosen).
z GSM isn’t ready
If the SIM card is found missing, a
warning message will be generated.
Panel SIM Card?
This indicates that you need to insert
the GSM SIM Card. Please refer to
Page 16, IV Special Settings,
Section 14.
Panel GSM PIN Code
You will need to set up your own
PIN code.
Panel GSM Signal?
Please change the position of CTC-
1132 control panel to get better
GSM signal.
Panel GSM Fault
Please re-start your CTC-1132
control panel
Panel GSM PUK?
SIM Card has been locked, please
call your service provider for help.
1. Fault Message Display
z When any fault situation persists, the
Control Panel will respond as below when
it is in Disarmed mode:
The Yellow LED will light to indicated
the fault condition
The LCD will display the type of fault
and the source of the fault in the
“Fault Display” section of the User
Menu.
A warning beep will sound at every
30 seconds.
If a fault condition is detected while
the system is in full arm mode, the
fault event display will not be
generated until the system is
disarmed.
2. Clearing Fault Message Display
z The Yellow LED will turn off automatically
once all of faulty conditions are restored, or
any faulty devices are removed. It cannot
be cleared manually.
z On the contrary, the fault message display
retains even if the faulty conditions have
been restored.
z The fault message can only be cleared
manually after the fault condition has been
rectified.
3. Viewing/Clearing the Fault
Message
To check what the fault condition is,
Step 1. When the system is in Disarmed mode.
Enter your PIN Code followed by “OK”.
Step 2. The screen will display
F a u l t D s p
Arm
and the cursor stays at “Fault Dsp”
Step 3. Press “OK” to select “Fault Dsp”
Step 4. All the fault events are listed. Use
“S” ,”T” key to move the cursor
downwards or upwards. The screen
To Next Page
