CTC-1132 868AM 2007.07.18
36
detected for 30 seconds, the yellow
LED will light up and the fault
message can be viewed under the
“Fault Display”..
5. Fault Message Nomenclature
z The fault event message is displayed in
short form as below:
Fault Condition
―
Message displayed
Interference
―
“Interference”
AC Power Fail
―
“AC failure”
Control Panel low
battery
―
“Panel L.B.”
Control Panel
sabotaged
―
“Panel Tamper”
Sensor Low Battery
―
(Sensor w/ Zone
Name) + “L.B.”
Sensor Sabotaged
―
(Sensor w/ Zone
Name) + “Tamper”
Sensor out-of-order
―
(Sensor w/ Zone
Name) + “out”
GSM out of Signal
―
“GSM Signal”
GSM module missing
―
“GSM Missed”
GSM Pin Code,
Incorrect/missing
―
“GSM Pin Code”
GSM locked by PUK
―
“GSM PUK”
SIM Card missing
―
“GSM isn’t Ready”
<
<
E
E
X
X
A
A
M
M
P
P
L
L
E
E
>
>
If “DC Z 01 L.B.” is displayed, it means
Zone 1 Door Contact is low battery.
<
<
N
N
O
O
T
T
E
E
>
>
) While you arm the system, if any of
Door Contact or PIR is triggered,,
arming is also prohibited and the
sensor triggered will be displayed as
fault message.
Sensor triggered Message displayed
Door Contact
triggered
(DC w/ Zone Name) +
“open”
PIR triggered
(IR w/ Zone Name) +
“Active”
6. Remote Control Command
The Unit can be controlled by Remote Control
Commands sent via SMS messages.
A. From Regular Phone Lines
Step 1. Dial the GSM phone number of your
Control Panel and hang up on the first
ring.
Step 2. Dial the Control Panel again after
8~20seconds.
Step 3. You will hear 2 beeps from the Control
Panel via phone set.
Step 4. Enter the user pin code (user 1 ~ user
4).
Step 5. If the pin code is correct, you will hear
2 beeps from the Control Panel via
phone set.
<
<
N
N
O
O
T
T
E
E
>
>
) In Step 5, the first digit of pin code
should be entered within 3 sec.
) In Step 5, a valid pin code should be
entered with 20 sec. otherwise the
Panel will hang up automatically.
Step 6. Enter the 2-digit DTMF Control
Command. When the Command is correct,
you will hear 2 beeps; if the Command is
uncorrect, you will hear 1 beep.
To Next Page
