EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01Service Manual - DNG Series
15.4 Indoor Unit: DNG 30
15.5 Indoor Unit: DNG 37
No. Part No. Description Qty
1 473420 IU COIL GR/HDR DNG 30 1
2 473231 FLOAT SUPPORT DNG 1
3 473900 DNG METAL FILTER 18-30 1
4 473246 INSULATED DRAIN POOL ASSY DNG 1
5 473700 DNG OVER FLOW SWITCH 1
6 473210 COIL SUPPORT DNG 30 1
7 433432 P.C ASSY WITHOUT RELAY DNC 1
8 402713 WIRED DISPLAY BOX EMD/ELD 1
9 473905 FAN HOUSING ASSY DNG 30 1
11 473248 AIR FILTER FRAME ASSY DNG 18-30 1
12 473250 MOTOR LEG ASSY DNG 3
16 436673 REMOTE CONTROL RC4/RC 1
18 442019 CAPACITOR 8mF 400V P1/P2 1
19a 473720 THERMISTOR+CAP WITH CONNECTOR 1
19b 473710 THERMISTOR WITH CONNECTOR L235 1
7a 402730 CABLE 8 WIRES 7M WTH CONNECTOR 1
9a 473007 MOTOR DNG 30 1
9b 473300 CENTRIFUGAL FAN DNG 300/100 1
No. Part No. Description Qty
1 473430 IU COIL GR/HDR DNG 37 1
2 473231 FLOAT SUPPORT DNG 1
3 473902 DNG METAL FILTER 37-44 1
4 473247 INSULATED DRAIN POOL ASSY DNG 1
5 473700 DNG OVER FLOW SWITCH 1
6 473245 COIL SUPPORT DNG 37 1
7 433432 P.C ASSY WITHOUT RELAY DNC 1
8 402713 WIRED DISPLAY BOX EMD/ELD 1
9 473906 FAN HOUSING ASSY DNG 37-44 1
11 473249 AIR FILTER FRAME ASSY DNG 37-44 1
12 473250 MOTOR LEG ASSY DNG 3
16 436673 REMOTE CONTROL RC4/RC 1
18 442019 CAPACITOR 8mF 400V P1/P2 1
19a 473720 THERMISTOR+CAP WITH CONNECTOR 1
19b 473710 THERMISTOR WITH CONNECTOR L235 1
7a 402730 CABLE 8 WIRES 7M WTH CONNECTOR 1
9a 473006 MOTOR DNG 37 1
9b 473301 CENTRIFUGAL FAN DNG 300/130 1
