EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01
Service Manual - DNG Series
15.2 Indoor Unit: DNG 18
15.3 Indoor Unit: DNG 24
No. Part No. Description Qty
1 473400 IU COIL GR/HDR DNG 18 1
2 473231 FLOAT SUPPORT DNG 1
3 473900 DNG METAL FILTER 18-30 1
4 473246 INSULATED DRAIN POOL ASSY DNG 1
5 473700 DNG OVER FLOW SWITCH 1
6 473244 COIL SUPPORT DNG 18-24 1
7 433432 P.C ASSY WITHOUT RELAY DNC 1
8 402713 WIRED DISPLAY BOX EMD/ELD 1
9 473907 FAN HOUSING ASSY DNG 18-24 1
11 473248 AIR FILTER FRAME ASSY DNG 18-30 1
12 473250 MOTOR LEG ASSY DNG 3
16 436673 REMOTE CONTROL RC4/RC 1
17 489117 RELAY AC, SPST, 30A 1
18 442019 CAPACITOR 8mF 400V P1/P2 1
19a 473720 THERMISTOR+CAP WITH CONNECTOR 1
19b 473710 THERMISTOR WITH CONNECTOR L235 1
7a 402730 CABLE 8 WIRES 7M WTH CONNECTOR 1
9a 473008 MOTOR DNG 18/24 1
9b 473300 CENTRIFUGAL FAN DNG 300/100 1
No. Part No. Description Qty
1 473410 IU COIL GR/HDR DNG 24 1
2 473231 FLOAT SUPPORT DNG 1
3 473900 DNG METAL FILTER 18-30 1
4 473246 INSULATED DRAIN POOL ASSY DNG 1
5 473700 DNG OVER FLOW SWITCH 1
6 473244 COIL SUPPORT DNG 18-24 1
7 433432 P.C ASSY WITHOUT RELAY DNC 1
8 402713 WIRED DISPLAY BOX EMD/ELD 1
9 473907 FAN HOUSING ASSY DNG 18-24 1
11 473248 AIR FILTER FRAME ASSY DNG 18-30 1
12 473250 MOTOR LEG ASSY DNG 3
16 436673 REMOTE CONTROL RC4/RC 1
18 442019 CAPACITOR 8mF 400V P1/P2 1
19a 473720 THERMISTOR+CAP WITH CONNECTOR 1
19b 473710 THERMISTOR WITH CONNECTOR L235 1
7a 402730 CABLE 8 WIRES 7M WTH CONNECTOR 1
9a 473008 MOTOR DNG 18/24 1
9b 473300 CENTRIFUGAL FAN DNG 300/100 1
