15-42
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01
Service Manual - DNG Series
15.44 Outdoor Unit: OU10-44 ST 3PH
Item Code Item Description Quantity
Drawing
Number
437045 UPPER COVER EL13 OU LARGE 1 1
439655 SIDE PANEL OU10 1 2
436357 SMALL ELECTRICAL COVER OU 1 3
439653 FRONT PANEL OU10 1 4
439662 GRILLE OU10 2 5
439841 NEW BASE ASSY OU LOCAL 1 6
433876 COIL OU10-44 ST GR R410A 1 7
439650 AXIAL FAN D400*112 2 8
439651 MOTOR 70W,3S,OU10-50 2 9
430838 SIDE NET PANEL EL13 OU10-44Z 1 10
436358 OU LEADING HANDLE 1 11
439657 MOTOR SUPPORT OU10 1 12
190442 HEATER CRANKCASE OU10 LG 1 13
438764 COMPRESSOR ARA053YAA 1 14
433929 CAPILLARY ASSY OU10-44 ST R410 1 15
433933 TUBING ASSY OU10-44 ST R410A 1 16
402494 BOARD TPHN 3C 1 17
442017 CAPACITOR 3mF 400V P1/P2 2 18
434716 THERMISTOR+CAP WTH CONNECTOR L 1 19
435545 COMPRESSOR WIRING WTH PLUG L12 1 21
402284 SUCTION ACCUMULATOR 5" x 3/4" 1 22
439661 CONES OU10 2 23
437229 ELECTRICAL BOX TPHN 1 24
439795 3PH MOTOR PROTECTOR 1 25
436352 RAISING HANDLE OU10 1 26
439656 SIDE COVER OU-8/10 1 28
