Electra FS 1200 - Page 5

Model:
FS1200T R407c COOLING CAPACITY
10,000
11,000
12,000
13,000
14,000
15,000
16,000
17,000
18,000
10 15 20 25 30 35 40 45
Outdoor Temp. (C DB)
CAPACITY [W)
30 C DB/50%RH
26 C DB/50%RH
23 C DB/50%RH
Indoor Temp.
FS1200T R407c HEATING CAPACITY
6,000
8,500
11,000
13,500
16,000
18,500
21,000
-10 -5 0 5 10 15
Outdoor Temp. (C DB)
CAPACITY [W)
20 C DB
18 C DB
15 C DB
Indoor Temp.
FS KFR 120L
Rev.: 01
Series: FS
Date: 20/02/2004
ELECTRA CONSUMER PRODUCTS LTD
