Electro-Sensors TR400 User Manual

25
Rev G
S5−
−−
−TR400 Programming
Programmable variables, continued
Var # Variable Name Description
See Page
Default
Value
User
Value
14 Input Function
Selection
The configuration for the switch inputs.
39
0000
15 Display Value at 4
mA
The rate-display value to be represented at 4 mA
output.
38
0000
16 Display Value at 20
mA
The rate-display value to be represented at 20
mA output.
38
1800
17 Range Selection The time it takes the display to zero out.
34
0500
18 Display Unit Interval The time in seconds for the display to update.
34
000.5
19 Analog Output
Response Time
The response time of the analog output in
percent. The analog output changes with input
frequency changes.
38
000.0
20 Modbus Node
Address
Address the TR400 resides on the network
Addendum
0001
21 Modbus Baud Rate 0 = 2400, 1 = 4800, 2 = 9600, 3 = 19200, 4 =
38400
Addendum
0003
22 Analog Output cutoff
%
The percent of full scale where the analog cuts
off to zero output. It can be set from 0.0 to 10.0
percent.
38
000.5
23 Pulses to Average The number of pulses to average to smooth out
the display and analog
32
0000
24 Averaging window Sets the window in which the pulses will be
averaged. Exceeding it makes it operate pulse to
pulse.
32
0005
25
26 Display features Leading Zero blanking and bright/dim display
40
0011
27
28
33-35 Reserved ----
36 Output 3 Value Holds the set-point value for output “3” in
display units.
36
0600
37 Output 3 Delay Time The amount of time that the set-point condition
must exist before the output will deactivate.
37
001.0
38 Output 3 On Time The minimum time that the output will stay
inactive when a set-point condition occursup
to 600 seconds. The output latch code value is
999.9.
37
001.0
39 Output 4 Value Holds the set-point value for output 4 in display
units.
36
0500
40 Output 4 Delay Time The amount of time that the set-point condition
must exist before the output will deactivate
37
001.0
41 Output 4 On Time The minimum time the output will stay inactive
when a set-point condition occursup to 600
seconds. The output latch code value is 999.9.
37
001.0
42 Relays 3 & 4 Output
Function
Selects the set-point function of the relay outputs
and the direction required for activation.
35
0000
Continued on next page
