−TR400 Programming
Programmable variables
Variables
Table 4 describes the programmable variables for the TR400.
Table 4: TR400 Programmable Variables
Var # Variable Name Description See Page Default
Values
User
Values
00 Security Match Code This value is compared to the security code
number, which is programmed in diagnostics.
Record the value in diagnostics not variable 00.
• Numbers match = Unlocked
• Numbers don’t match = Locked
Keypad lockout options are set in variable 05.
48 0400
01 Max RPM Maximum Revolutions Per Minute. 32 1800
02 PPR Pulses Per Revolution. 32 0008
03 Display Units The value displayed when a monitored shaft is
turning at the speed programmed in variable 01,
Max RPM.
32 1800
04 Rate Function Selects the display and input signal types. 33 0000
05 Keypad Lockout Selects the function keys that are enabled or
disabled when security is set (keypad lockout
function).
48
06 Start-Delay Time Upon power-up or after initiating a Reset, the
relays are turned on, regardless of the set-point
condition, for the amount of time in seconds
entered in this variable, up to 600 seconds. The
start-delay time allows the process to reach
normal operating speed.
36 001.0
07 Output 1 Value Holds the set-point value for output “1” in
display units.
36 1500
08 Output 1 Delay Time The amount of time that the set-point condition
must exist before the output will deactivate.
37 001.0
09 Output 1 On Time The minimum time that the output will stay
inactive when a set-point condition occursup
to 600 seconds. The output latch code value is
999.9.
37 001.0
10 Output 2 Value Holds the set-point value for output 2 in display
units.
36 1000
11 Output 2 Delay Time The amount of time that the set-point condition
must exist before the output will deactivate
37 001.0
12 Output 2 On Time The minimum time the output will stay inactive
when a set-point condition occursup to 600
seconds. The output latch code value is 999.9.
37 001.0
13 Relay Output 1 & 2
Function
Selects the set-point function of the relay outputs
and the direction required for activation.
35 0000
Continued on next page
