Appendix A:
TR400 Specifications
Power Description
Input Power
•
115 Vac, 6VA @ 50/60 Hz, requires external fuse 1/16 amp slow-
blow
•
230 Vac, 6VA @ 50/60 Hz, requires external fuse 1/32 amp slow-
blow
•
10-30 Vdc requires external fuse 2 amp slow- blow
Sensor Description
Sensor Supply 12 Vdc unregulated up to 100mA for 115 and 230 Vac units.
12 Vdc regulated up to 100mA for 10-30 Vdc units, max 2 relays.
12 Vdc regulated up to 50mA for 10-30 Vdc units with 6 relays.
Sensor Input Switch selectable
NPN Open Collector 2200 ohm pull-up to 12 Vdc, 2.5 volts trigger level
PNP Open Collector 2200 ohm pull-down, 2.5 volts trigger level
Logic Level 2.5 volts trigger level
Magnetic Pickup 150 mV peak-to-peak minimum signal, 50 mV trigger level
Maximum Frequency Up to 4 kHz (consult factory for higher frequencies)
Optional External Control
I/O
Description
Switch Inputs 3 programmable inputs
Set Point Outputs (Relays) 2 or 6 programmable-form C relays on board, rated 250 Vac 5 amp, 30
Vdc 5 amp resistive load With option for 8 external relays.
Analog Outputs 1 programmable 4-20 mA or 0-10 VDC output, 12 bit
