31
Rev G
S5
TR400 Programming
How to select and change a variable’s numerical value, continued
Changing the
value
To change the PPR from 8 to 16 for variable 02, press each key the number of times
shown in the three (3) steps below, while viewing the results on the display.
Saving the
Value and
exiting
To save the new value and exit Program Mode, press the ENTER key shown in Step
7 below, and view the result on the displaythe PROG LED is OFF.
ENTER
REV PROG
OUT
1
KEY
ERR
OUT
2
0 0 0 0
0 0 0 6
REV PROG
OUT
1
KEY
ERR
OUT
2
0 0 0 6
REV PROG
OUT
1
KEY
ERR
OUT
2
0 0 1 6
REV PROG
OUT
1
KEY
ERR
OUT
2
Step 4
Step 5
Step 6
Step 7
2 Presses
Press
Press
Press
Meter idle display (Program Mode exited)
LED OFF
