SOI/DT 2003 - 01 eb 13 599 35 63-72
5 STRUCTURAL CHARACTERISTICS
5.1 Structure
The appliance as a whole may be considered as consisting of
four main assemblies:
BASE – DOOR – TUB – HYDRAULIC SECTION
The four assemblies are enclosed in a structure consisting of:
- A lower front panel (secured by two screws)
- Two lateral panels (secured by six screws).
5.2 Hydraulic and functional characteristics
Drying duct
Softener
Fill tank + condenser
Drain pump
Wash pump
Heater
Counterweight
Base
Sump
