Electrolux DIVA 60 - Specifications for Actuators and Sensors; Components; Sensors

SOI/DT 2003 - 01 eb 16 599 35 63-72
6.2 Specifications for actuators and sensors
6.2.1 Components
TYPE OF COMPONENT POWER AVAILABLE
TYPE OF ELECTRONIC
CONTROL
Wash pump Max 250W Triac
Drain pump Max 100W Triac
Heating element Max 2100W Relay
Water fill solenoid Max 10W Triac
Regeneration solenoid Max 10W Triac
Detergent and Rinse-aid solenoid Max 10W Triac
Fan motor Max 10W Triac
6.2.2 Sensors
TYPE OF SENSOR
TYPE OF ELECTRONIC
SIGNAL
TYPE OF
COMPONENT
Salt sensor Digital 5 Volt Reed
Rinse-aid sensor Digital 5 Volt Reed
Temperature sensor Analogue 5 Volt * NTC
Turbidity sensor
(certain models only)
Analogue 5 Volt Opto-electronic
Tachymetric sensor Frequency Tachymetric generator
Level sensor Digital - High voltage Pressure switch
Door closure sensor Digital - High voltage Switch
Anti-flooding sensor Digital - High voltage Switch
* NTC Temperature sensor
* NTC COMPARATIVE VALUES
Temperature
°C

Nominal value
Ω
ΩΩ
Ω
10

9655
25

4850
60

1205
90

445
