87
3. Disconnect the wire harness and release the spring
loaded locking tab on the side of the control board
house. Lift the side of the housing up, slide the
assembly to the rear to disengage the front tab and
lift the assembly away from the washer base.
4. From the front of the washer, tip the bottom of the
assembly toward the motor and slide the assembly
out between the shock absorber and the motor.
5. Release the latch on each end of the speed control
housing and raise the top flap.
6. Unplug the (2) plugs and the ground wire and remove
the speed control assembly from the washer.
7. To remove the control board from the housing,
release the latch on each end at the top and lift the
back open.
