8.3.5.2 Using an analog input
This example illustrates how to connect with an analog sensor.
8.4 Ethernet
The Ethernet is provided on the top of the control box. Please refer to the figure below.
The Ethernet interface can be applied to the following applications:
• Remote access and control
The electrical specifications are shown below.
Parameter Min Type Max Unit
Communication speed 10 - 100 Mb/s
