How to replace the heating
© Elma GmbH & Co KG SM/Transsonic_LC/1104/D
45
9.1.2 Wiring 230V
Both heating elements are wired in a line.
2 heating elements are wired in a line. The third element is
connected parallel to the two other elements.
2 elements each are wired in a line and connected parallel with
the other element pairs.
2 Heating elements
3 Heating elements
4 and more heating
elements
