How to replace the transducer tank
54
SM/Transsonic_LC/1104/D © Elma GmbH & Co KG
9. Degrease and clean the glueing surfaces of the housing
edge and the edge of the (new) transducer tank with
alcohol.
10. Fill new silicone sealing (e.g. Teroson) along the tank edge.
11. Position the unit housing in the sealing mass. Ensure
correct front and backside positioning.
12. Let the sealing mass harden (approx. 12 h / or according to
the instructions of the manufacturer).
13. On units with drain duct:
Mount the drain duct: Wipe all duct threads with a wire
brush to remove any sealing remains and clean with
alcohol. Seal the thread e.g. with Loctite 586 or Teflon tape
(see also section 12).
14. Reconnect all electric cables.
Heat up silicone
sealing and cut
Illustration 11.1.1. Heat up the silicone sealing in the tank edge and
cut with a knife.
