How to replace components
on the generator print
84
SM/Transsonic_LC/1104/D © Elma GmbH & Co KG
Secondary coil (102 wraps) T1040H; T1060H: 200 000 7112
Illustration 15.4.3. Generator print with relevant components
Transistors
HF diodes (BA 159 or DSEI8-06A on T1040-T1060 115V )
Varistor
Output transformer (secondary coil)
Output capacitor (4 pieces)
D
B
A
B C
E
A
B
C
D
E
