SPECIFICATIONS
7
SPECIFICATIONS
English
P
1~
P
32
General
Item Specifi cations
Power source 12VDC (AC adapter AC100 - 240V)
Power consumption 9W (AC adapter included)
Outside dimensions
W343xD368xH411mm (W13.5xD14.5xH16.2 in) (When setup)
W195xD368xH444mm (W7.7xD14.5xH17.5 in) (When folded)
Weight Approx. 2.9kg (6.4 lbs) (Main body only)
Input selection Main/External
Output terminal RGB output Mini Dsub 15P connector, female x 1
Composite video output RCA pin jack/75
Ω
unbalanced x 1
(NTSC / PAL)
Input terminal Input terminal RGB input Mini Dsub 15P connector female x 1
∗
Use pin plug for RCA pin in accordance with EIAJ RC-6703.
Main Camera
Item Specifi cations
Lens f = 4.0mm - 21.2mm (5.3-time zoom) F2.0 - 4.5
Frame rate Max. 20 frames/sec.
Shooting area Max. 426x317mm (16.8x12.5 in) Min. 93x70mm (3.7x2.7 in)
Limit of focus
adjustment
50mm -
∞
(2.0 in x
∞
) from lens top
Optical zoom 5.3X
Digital zoom 8X
Focus Auto/Manual
Image pick-up element
1/3” CCD
Total pixels Horizontal 1077, Vertical 788 ... Approx. 850,000 pixels
Effective pixels Horizontal 1024, Vertical 768
Synchronized signal Internal
Resolution Analog RGB
Horizontal 600TV lines or more Vertical 600TV lines or more
Video output Horizontal 400TV lines or more
Analog RGB output Analog RGB output 0.7 V(p-p) 75
Ω
unbalanced
Synchronized signal: Negative polarity
XGA Horizontal frequency 48.363 KHz
Vertical/horizontal frequency 60.004 KHz
Compliant with VESA
Composite video output
Compliant with NTSC/PAL
White balance Full auto/One-push/Manual
Video output selection switch
Provided (NTSC/PAL)
Brightness control Auto (level control provided)/Manual
Posi/Nega conversion Provided
Color/B&W selection Provided
Image rotation Provided (0°/180°)
Mode
Text1/Text2/Text3/Graphics
Gamma setting Provided (Only for graphic mode))
Edge enhancement Provided (Only for graphic mode)
Pause Provided
∗
The above specifications are subject to change without notice.
