Setting Up
1
Turn the camera head.
2
Connect the analog RGB cable to the
[RGB OUT] terminal and connect the
DC plug of AC adapter to [DC IN 12V]
terminal.
P. 1 5
3
Turn the power switch of the main unit
ON.
90°
Note
• Proper set up position of the camera head is as
shown in the right figure.
Never apply excessive force to the camera head.
Note
• Be sure to hold the lower part of the main unit in
both hands when carrying the unit. Never hold
the column or the camera head
• Pay attention to prevent the camera head from
knocking against the desk or the like.
