ELNA 7300 - Replacing the Bobbin Case; Changing the Light Bulb

168
Changing the Light Bulb
Tu r n OFF the power switch. Unplug the machine.
Wait until the bulb has cooled before touching it.
Remove screw q. Pull away face plate w.
Swing light socket e to left and pull out light bulb r.
Insert light bulb into light socket. Return light socket to
original position.
Replace face plate and tighten screw.
NOTE: Only use same type light bulb rated 12 Volts,
5 watts.
q
w
e
r
e
w
q
Replacing the Bobbin Case
Insert the bobbin case so the knob q fits next to the
stopper w in the hook area. The red triangle marks e
on the bobbin case and stopper must align with each
other.
Attach the needle plate and tighten the screws.
After cleaning, be sure to replace the needle, presser
foot and bobbin.
