34
w
q
r
y
u
r
To disengage the Dual Feed Device
Pull down the Dual feed device w and swing it to
the rear to disengage. Push up the Dual feed
device until the notch of the Dual feed device
catches the pin e.
Detaching the Dual Feed Foot
Raise the needle and the presser foot lifter q
to its extra lift position.
Loosen the thumb screw r and remove the Dual feed
foot t.
Attach the presser foot holder y to the presser
bar u.
Tighten the thumbscrew by turning it clockwise
lightly.
Lower the presser bar.
Depress the foot against the needle plate, and
loosen the thumbscrew slightly.
Tighten the thumbscrew firmly.
t
Set the presser foot lifter to normal position.
z
x
z
x
z
x
c
z
x
c
e
q
