ELTEC BAB 740 - Page 53

Jumpers
Jumpers User's Manual
BAB 740
5—3
Table 22: SMI Interrupt Routing (J1701)
J1701 Function
- no SMI interrupt
1-3 route Universe INT0 to SMI
2-4 route Universe INT0 to SMI
4-6 route Universe INT0 to SMI
3-5 route Universe INT0 to SMI
7-8 route SMITICK to SMI (default)
Table 23: Universe PCI Interrupt Routing (J1702...J1705)
J1702 Function
- no Universe INT0, INT1 on PCI
1-2 route Universe INT0 to PCI IRQ A
2-3 route Universe INT1 to PCI IRQ A
J1703 Function
- no Universe INT2, INT3 on PCI
1-2 route Universe INT2 to PCI IRQ B
2-3 route Universe INT3 to PCI IRQ B
J1704 Function
- no Universe INT4, INT5 on PCI
1-2 route Universe INT4 to PCI IRQ C
2-3 route Universe INT5 to PCI IRQ C
J1705 Function
- no Universe INT6, INT7 on PCI
1-2 route Universe INT6 to PCI IRQ D
2-3 route Universe INT7 to PCI IRQ D (default)
Table 24: VMEBus SYSRESET (J1706, J1902)
J1706 J1902 Function
- - no VMEbus SYSRESET
short - VMEbus SYSRESET is input
- short VMEbus SYSRESET is output (default)
Short Short not allowed
