Jumpers
Jumpers
User's Manual
BAB 740
5—4
Table 25: VMEBus SYSFAIL (J1901)
J1901 Function
Open no VMEbus SYSFAIL
short VMEbus SYSFAIL output enable (default)
Table 26: COM3 Configuration (J2201, J2202, X2201)
J2201 J2202 X2201 Configuration
1-2 1-2 SILC-200 RS232 async.
3-5 5-6 (default)
6-8
2-4 1-2 SILC-200 RS232 sync.
6-8 4-6
6-8 1-2 SILC-300 RS422 async.
4-6 2-4 SILC-300 RS422 sync.
Table 27: COM4 Configuration (J2203, J2204, X2202)
J2203 J2204 X2202 Configuration
1-2 1-2 SILC-200 RS232 async.
3-5 5-6 (default)
6-8
2-4 1-2 SILC-200 RS232 sync.
6-8 4-6
6-8 1-2 SILC-300 RS422 async.
4-6 2-4 SILC-300 RS422 sync.
