16 Display Operation Manual BC2000 and JC2000 Controller ~ Doc. No. 2055882, Issue 5.1, June 2014
Figure 9 - Page 1: System Status
Date and Time
The next page is accessed with a single clockwise turn of the scroll knob. This page
displays the date and time.
Figure 10 - Page 2: Date and Time
To change the date and time, see the section “Change System Time and System
Date” on page 21.
Profile and Preset
The last page is accessed with another single clockwise turn of the scroll knob. This
page displays the controller profile number and the preset.
Profiles are prescribed settings negotiated with Eltek for custom parameter values
and alarm mappings. The default profile number for 48V systems is “A01”. On the
profile page, this profile is displayed as “1A01-10VC”. The default profile number for
24V systems is “B01”. If a profile number other than A01 or B01 is displayed, then it
is a custom profile.
Presets are subsets of profiles. Up to three presets can be configured for
parameter values only (not alarm mapping). These three presets are typically called
“A”, “B”, and “C”. Preset A is the default preset.
Internal 30C
54.00V 100A
Menu
System OK
Page 1
System Status
Internal Temperature
System Voltage
Total Rectifier Current
10/12/2006
13:55:32
54.00V 100A
Menu
Date & Time
Page 2
Date
Clock
To Next Page
