Display Operation Manual BC2000 and JC2000 Controller ~ Doc. No. 2055882, Issue 5.1, June 2014 23
Main Menu ► Generator
The following setpoints are configurable:
• State—enable or disable the generator feature
• Type—select the type of generator: “Air Cooled” or “Other”
• Battery AH—enter the ampere-hour rating of the connected battery string
• DischargeLVL—set the percentage of the battery string’s ampere-hour
capacity at which the generator should turn on and begin recharging the
batteries
Other information available on this page:
• Available AH—real-time calculation of the battery string’s remaining available
ampere-hours
• Available AM—calculation of the battery string’s remaining available ampere-
minutes
• Available Min—the battery string’s estimated remaining discharge time in
minutes
For further details, including feature behavior, see document 2045453 – BC2000
Diesel Generator Interface Guide.
Restore Preset
The presets are factory values for all parameters shown in Table 5 and the alarm
relay configuration. By default all three presets are identical for profile 01. These
presets can be used to return the system to default settings (requires an
administrator login). Presets are non-adjustable, but custom presets can be
requested through Eltek.
Main Menu ► Preset ► Current ► Edit
Form-C Relay
Output
To Next Page
