3 About Power System Configuration
User's Guide Smartpack2 Master Controller 350020.013, Issue 2.0, 2014 Jan 21
automatic configuration of specific functions
The “nn” in the file name specifies the unit’s CAN bus address.
Software Upgrade
which offers you to upgrade the firmware in connected controllers and
control units, by uploading files stored in the controller’s data storage device.
Read chapter “SD Card Storage - Overview Firmware Files (Binary
Format)”, page 21
Example of some of the available options in controller’s submenu:
Up/Download > Software Upgrade
SD Card Storage - Overview Firmware Files (Binary Format)
You can store binary files in the Smartpack2 Master controller’s SD card (data storage
device) and use them for firmware upgrading of controllers and control units, as well as for
exporting and importing configuration files.
NOTICE:
All firmware upgrade and configuration files stored in the SC card
must have specific file names.
The SD card uses the 8.3 file name format. Before storing the files on the SD card, you
must rename them, so that they conform to the specific file names described below.
For example, if you receive the file “SmartPack2_Basic_405007.009_V1.1.mhx” to
upgrade your Smartpack2 Basic controller firmware to version 1.1, you must first rename
the file to exactly “SP2BAS.MHX”, then copy the file to the SD card and finally insert the
SD card in the Smartpack2 Master controller to start the firmware upgrade process.
Smartpack2 Basic Industrial
Control Units:
I/O Monitor, Monitor2 & Monitor3
Configuration File (Save/Load)
The “aa” refers to the CAN bus address or ID number.
E.g. “UNIT_82.HEX” could be the configuration file for I/O Monitor with CAN bus address 82.
