Eltek Smartpack2 User Manual

3 About Power System Configuration
User's Guide Smartpack2 Master Controller 350020.013, Issue 2.0, 2014 Jan 27
Parameters for Analogue Alarm Monitors (A2)
Example to monitor analogue values such as voltage, current, etc with 2 limits.
#
Description
Value
Unit/Label
Note
Monitor – Enable/Disable?

Enable
Activates or deactivates the alarm monitor
Manual Reset
Disabled
Or “All Levels” or “MajorHigh Only” (a)
Hysteresis
100
Amp
(b)
TimeDelay
5
Seconds
Selects among delay time options (b)
MajorHigh AlarmLevel
5000
Amp
Upper limit
MajorHigh AlarmGroup
Major Alarm
Selects the alarm group to activate
MinorHigh AlarmLevel
4000
Amp
Lower limit
MinorHigh AlarmGroup
Minor Alarm
Selects the alarm group to activate
Parameters for Analogue Alarm Monitors (A4)
Example to monitor analogue values such as voltage, current, etc with 4 limits.
#
Description
Value
Unit/Label
Note
Monitor – Enable/Disable?

Enable
Activates or deactivates the alarm monitor
Manual Reset
Disabled
Or “All Levels” or “MajorHigh Only” (a)
Hysteresis
10
Volt AC
(b)
TimeDelay
7
Seconds
Selects among delay time options (b)
MajorHigh AlarmLevel
280
Volt AC
Major High upper limit
MajorHigh AlarmGroup
Mains Alarm
Selects the alarm group to activate
MinorHigh AlarmLevel
260
Volt AC
Minor High upper limit
MinorHigh AlarmGroup
Mains Alarm
Selects the alarm group to activate
MinorLow AlarmLevel
100
Volt AC
Minor Low lower limit
MinorLow AlarmGroup
Mains Alarm
Selects the alarm group to activate
MajorLow AlarmLevel
80
Volt AC
Major Low lower limit
MajorLow AlarmGroup
Mains Alarm
Selects the alarm group to activate
Parameters for Special Alarm Monitors (LVD)
Example to monitor the battery voltage and control the LVD contactors.
#
Description
Value
Unit/Label
Note
Monitor – Enable/Disable?

Enable
Activates or deactivates the alarm monitor
MainsIndependent Enable/Disable?

Enable
(c)
Temp. Dependant Enable/Disable?

Enable
(d)
Disconnect Voltage [V]
43,00
(e)
Reconnect Voltage [V]
48,00
(f)
Delay After Disconnect [seconds]
000
Selects among delay time options (g)
AlarmGroup
LVBD
Selects the alarm group to activate
Minor Low lower limit
Selects the alarm group to activate
Major Low lower limit
Selects the alarm group to activate
The LVD alarm monitors “observe” that the battery voltage (input signal) is within limits,
otherwise they activate the LVD contactors (alarm group).

Eltek Smartpack2 Specifications

General

Type	Power System Controller
Input Frequency	45 - 65 Hz
Operating Temperature	-40°C to +70°C
Communication Ports	RS232, Ethernet
Protocols	Modbus, SNMP
Protection Features	Overvoltage, Overcurrent, Over Temperature
