3 About Power System Configuration
30 User's Guide Smartpack2 Master Controller 350020.013, Issue 2.0, 2014 Jan
The example below shows typical Alarm Output Group assignment in a Smartpack S-based
system.
Alarm Configuration > Outputs
#
Description
Alarm Groups
Output
1
2
3
4
5
6
LVBD
LVLD1
Note
1
Major Alarm, AOG






2
Minor Alarm, AOG






3
Mains Alarm, AOG






4
Fuse Alarm, AOG






5
High Battery Alarm, AOG






6
Low Battery Alarm, AOG






7
Rectifier Alarm, AOG






8
Gen-Set AOG






9
Alarm Group 9






10
Alarm Group 10






---






---






17
Alarm Group 17






18
OutpBlocked, AOG






19
LVBD, AOG







20
LVLD, AOG 1







-----






-----






In the example above,
 Alarm relay output 1 is used for external common alarm signalling
 Alarm Output Group 18, “OutpBlocked, AOG”
If an external warning is necessary, you can assign output relays to the
“OutpBlocked, AOG” group, e.g. to activate a lamp or alarm bell when the
alarm output relays are blocked.
Read more in topic “Alarm Outputs Isolation (Output Blocked)” on page 31
 Alarm Groups 9 through 17 are unused, and can be assigned when required
