106 MES1000, MES2000 Ethernet Switches
show lldp statistics
[gigabitethernet gi_port |
fastethernet fa_port]
gi_port: (1..3/0/1..28);
fa_port: (1..3/0/1..24).
Show LLDP statistics.
Example execution of commands
 Define the following TLV fields for gi 1/0/1 port: port-description, system-name, system-
description. Add control address 192.168.17.55 for this interface
console# configure
console(config)# interface gigabitethernet 1/0/1
console(config-if)# lldp optional-tlv port-desc sys-name sys-desc
console(config-if)# lldp management-address 192.168.17.55
View LLDP configuration:
console# show lldp configuration
LLDP state: Enabled
Timer: 30 Seconds
Hold multiplier: 4
Reinit delay: 2 Seconds
Tx delay: 2 Seconds
Notifications Interval: 5 Seconds
LLDP packets handling: Filtering
Port State Optional TLVs Address Notifications
--------- ----------- -------------------- ----------------- ---------------
gi1/0/1 Rx and Tx PD, SN, SD 192.168.17.55 Disabled
gi1/0/2 Rx and Tx SC None Disabled
gi1/0/3 Rx and Tx SC None Disabled
gi1/0/4 Rx and Tx SC None Disabled
gi1/0/5 Rx and Tx SC None Disabled
gi1/0/6 Rx and Tx SC None Disabled
gi1/0/7 Rx and Tx SC None Disabled
gi1/0/8 Rx and Tx SC None Disabled
gi1/0/9 Rx and Tx SC None Disabled
gi1/0/10 Rx and Tx SC None Disabled
gi1/0/11 Rx and Tx SC None Disabled
gi1/0/12 Rx and Tx SC None Disabled
More: <space>, Quit: q or CTRL+Z, One line: <return>
Table 5.102 —Description of results
Field
Description
Timer
Define the frequency of LLDP updates sent by the device.
Hold multiplier
Specify the amount of time (TTL, Time-To-Live) for the receiving device to keep
LLDP packets before dropping them.
TTL = Timer * Hold multiplier.
Reinit delay
Define the minimum amount of time, that the port will wait before sending the next
LLDP message.
Tx delay
Define the delay between the subsequent LLDP frame transmissions, initiated by
changes of values or status.
Port
Port number.
State
Port operation mode for LLDP.
Optional TLVs
TLV options being sent
Possible values:
PD—port description
SN—system name
