EM TEST CNI 503 Series User Manual

EM TEST CNI 501 / CNI 503
Manual of operation V 3.32 16 / 41
4.5.
Test level with Burst as per IEC 61000-4-4 Ed.2.
Burst generators, which comply with the specifications of IEC 61000-4-4 Ed2: 2004, have a limitation of the
maximum output voltage. Then the maximum test level is limited by the number of coupling on several lines.
Please see the following limits:
Coupling
UCS 500 >Vers.3.0
UCS 500M4 >Vers.3.0
UCS 500N4
EFT 500 /
EFT 500 M4
EFT 500N5
UCS 500N5
UCS500M7
UCS 500M6B
UCS500N6
UCS 500M6 >Vers.3.0
UCS 500M6A >Vers.3.0
EFT 500N8
EFT 500 M8
50 
4800V
4800V
5500V
7000V
1 coupling any
4800V
4800V
5500V
7000V
2 couplings any
4800V
4800V
5000V
7000V
3 couplings any
4800V
4800V
5000V
7000V
Generator with
CNI 503 / CNE 503
CNI 501
UCS 500 >Vers.3.0
UCS 500M4 >Vers.3.0
UCS 500N4
EFT 500 /
EFT 500 M4
UCS500N5
EFT 500N5
UCS 500N5
UCS500M7
UCS 500M6B
UCS500N6
UCS 500M6 >Vers.3.0
UCS 500M6A >Vers.3.0
EFT 500 M8
50 
4800V
4800V
5500V
5500V
1 coupling any
4800V
4800V
5500V
5500V
2 couplings any
4000V
4000V
5000V
5000V
3 couplings any
4000V
4000V
5000V
5000V
4 couplings any
4000V
4000V
4500V
4500V
5 couplings any
4000V
4000V
4500V
4500V
4.6.
Decoupling inductors for surge pulse
To prevent unwanted voltage drops in the coupling/decoupling networks, the value of the decoupling element
generally must be reduced for coupling/decoupling networks rated at >25 A. The Table below shows the reduced
inductor values per line in function of the rated current.
Rated current
Inductance per line
16 A
1.5 mH
32 A
0.75mH
63 A
0.6mH
100 A
0.6mH
200 A
0.3mH
For this case, the “time to half value” of the open-circuit voltage waveform may be reduced in accordance with
Tables 6 and 7 in standard IEC 61000-4-5.
