EM TEST CNI 503 Series User Manual

EM TEST CNI 501 / CNI 503
Manual of operation V 3.32 6 / 41
1.2.
Coupling networks as per IEC, ANSI and Ringwave
Device
Impulse Phase Supply rated Current ac
Remarks
CNI 503 B5
7kV 3 3x480V 16A
CNI 503 B7
7kV 3 3x480V 32A
CNI 503 B8
7kV 3 3x480V 63A
RACK required
CNI 503 B9
7kV 3 3x480V 100A
RACK required
Device
Imp Phase Supply AC
Remarks
CNI 501 B9
7kV 1 AC 250V 100A
DC 75V 100A
- IEC 61000-4-5, ANSI/IEEE C62.41
- TEST ON function (possibility for Emergency Switch and
no Warning lamp control!!!)
CNI 503 B7.2
7kV 3 AC 3x480V 32A
DC 1000V 32A
- IEC 61000-4-5, ANSI/IEEE C62.41
- No TEST ON function (no possibility for an
Emergency Switch and no Warning lamp control!!!)
CNI 503 B7.3
7kV 3 AC 3x480V 32A
DC 1000V 32A
- IEC 61000-4-5, ANSI/IEEE C62.41
- TEST ON function (possibility for Emergency Switch and
Warning lamp control)
- Needs a rack to be ordered separately
CNI 503 B7.4
7kV 3 AC 3x690V 32A
DC 1000V 32A
- IEC 61000-4-5, ANSI/IEEE C62.41
- No TEST ON function (no possibility for an
Emergency Switch and no Warning lamp control!!!)
- Needs a UCS 500N7.2 or UCS 500N7.7
CNI 503 B7.5
7kV 3 AC 3x690V 32A
DC 1000V 32A
- IEC 61000-4-5, ANSI/IEEE C62.41
- TEST ON function (possibility for Emergency Switch and
Warning lamp control)
- Needs a UCS 500N7.2 or UCS 500N7.7 and a rack
CNI 503 B9.2
7kV 3 AC 3x480V 100A
DC 1000V 100A
- IEC 61000-4-5, ANSI/IEEE C62.41
- No TEST ON function (possibility for Emergency Switch
and Warning lamp control)
- Needs a rack to be ordered separately
CNI 503 B9.6
7kV 3 AC 3x480V 100A
DC 1000V 100A
- IEC 61000-4-5, ANSI/IEEE C62.41
- TEST ON function (no possibility for an
Emergency Switch and no Warning lamp control!!!)
- Needs a rack to be ordered separately
Coupling networks for the US are generally specified for a 3 phase power mains supply of 3x480Vrms.
It is forbidden to disconnect the plug in DC operation under voltage.
Risk of a stationary spark!
