EM TEST CNI 503 Series User Manual

EM TEST CNI 501 / CNI 503
Manual of operation V 3.32 7 / 41
1.3.
Special Coupling networks
Device
Impulse Phase Supply rated Current ac
Remarks
CNI 503 A.1
5.5kV 3 3x690V 16A
needs a UCS 500N5.2
CNI 503A S1
5.5kV 3 3x690V 16A
CNI 503A S2
5.5kV 3 3x690V 32A
CNI 503 A2.1
5.5kV 3 3x690V 32A
needs a UCS 500N5.2
CNI 503 A2.2
5.5kV 3 3x480V / DC 1000V 32A
No TEST ON function
CNI 503 A2.6
5.5kV 3 3x480V / DC 1000V 32A
With TEST ON function
500 VDC / 150 A
CNI 503A2.10
5.5kV 3 3x690V / DC 1000V 32A
No TEST ON function
CNI 503A3.1
5.5kV 3 3x690V 63A
requires MRAC or RAC 1000V dc
CNI 503A S3
5.5kV 3 3x690V 63A
requires MRAC or RAC
CNI 503A S4
5.5kV 3 3x690V 100A
requires MRAC or RAC
CNI 503B S1
7kV 3 3x690V 16A
CNI 503B S2
7kV 3 3x690V 32A
CNI 503B S3
7kV 3 3x690V 63A
requires MRAC or RAC
CNI 503B S4
7kV 3 3x690V 100A
requires MRAC or RAC
CNI 503B S7
7kV 3 3x208V 32A 400Hz
Burst 6.0kV
CNI 503 A14.1
8kV 3 3x480V 100A
requires Rack 32 or 34 UH
CNI 503 A12 S2
8kV 3 3x690V 32A
IEC @ANSI-B coupling (manual)
CNI 503 A16 S1
10kV 3 3x690V 16A
CNI 503A S22
4.4kV 3 3x480V 200A
requires MRAC or RAC
CNI 501B S3
7kV 1 250V 1000 VDC 32A
Ohne Test ON Function,
CNI 501 S4
10kV 1 250V 10A
CNI 501 S6
10kV 1 250V 16A
Generator impedance 2Ω
