EM TEST CNI 501 / CNI 503
Manual of operation V 3.32 35 / 41
12.2.3.
Multi Contact MC Locking system (AR-system)
The MC Locking system (AR) operates on the “push-pull” principle. It is self – locking when connected.
Disconnection is effected by an axially displaceable coupling ring: first push, then pull to disconnect. Dirty parts
should be cleaned with industrial alcohol before connecting.
Locking
Releasing
Insert plug into socket...
To release, push plug further in ...
... and lock!
... and pull!
To control: Apply tensile load!
The connection is released! 6
12.2.4.
100 A DC plugs and connectors from Multi Contact
The Multi Contact 10BV series is used for connecting
the 1000V DC supply. It is a single-pole round
connectors, insulated, Ø 10mm with bayonet
locking.
The panel receptable plug model is ID/S10BV-
C1/C4 with bayonet locking and threaded stud.
Couplers:
Models:
KBT10BV-AX/M25/50-70-C1
Order No 15.0646C1-22
KBT10BV-AX/M25/50-70-C4
Order No 15.0646C4-21
Note: To ensure interchangeability, the
following coding is recommended:
C1 (L1)
C4 (neutral)
For more information refer to the multi Contact power line 3 catalogue.
www.multi-contact.com
