EM TEST CNI 503 Series User Manual

EM TEST CNI 501 / CNI 503
Manual of operation V 3.32 5 / 41
1.
List of coupling networks
1.1.
Coupling networks for IEC pulses
Device
Impulse Phase Supply rated Current ac
Remarks
CNI 501
5.5kV 1 250V 32A
48V/32A dc
CNI 501 S1
5.5kV 1 250V 100A
75V/100A dc
CNI 503 A
5.5kV 3 3x480V 16A
CNI 503 A2
5.5kV 3 3x480V 32A
CNI 503 A3
5.5kV 3 3x480V 63A
RACK required
CNI 503 A4
5.5kV 3 3x480V 100A
RACK required
CNI 503 A4.1
5.5kV 3 3x440V 100A
EN 50121-4
CNI 503 A5
7kV 3 3x480V 16A
CNI 503 A7
7kV 3 3x480V 32A
CNI 503 A8
7kV 3 3x480V 63A
RACK required
CNI 503 A9
7kV 3 3x480V 100A
RACK required
CNI 503 A10
8kV 3 3x480V 16A
CNI 503 A12
8kV 3 3x480V 32A
CNI 503 A13
8kV 3 3x480V 63A
RACK required
CNI 503 A14
8kV 3 3x480V 100A
RACK required
CNI 503 A16
10kV 3 3x480V 16A
CNI 503 A18
10kV 3 3x480V 32A
CNI 503 A19
10kV 3 3x480V 63A
RACK required
CNI 503 A20
10kV 3 3x480V 100A
RACK required
