EM TEST VDS 200 Series User Manual

EM TEST VDS 200 Series
Manual for Operation V 5.19 29 / 57
3.5.
Setup
This menu helps the user to define the configuration of the VDS 200.
SETUP
F1 : Change language
F2 : LCD Backlighting
F3 : Interfaces
F4 : Keyboard-Beeper
F5 : Timer
F6 : Set voltage
F1
F2
F3
F4
F5
F6
F7
F1 Change language
The user can chose between two languages, German and English.
F2 LCD backlighting
With the use of F2 the backlighting can be switched ON or OFF. Additionally the AUTO-OFF function can be
programmed to switch off the backlighting after a defined time when the equipment has not been in operation (1 -
30 min).
F3 Interfaces
This menu will help the user to define the status of the integrated serial and parallel interfaces, e.g. the baud rate
of the RS 232 or the address of the IEEE interface.
F4 Keyboard beeper
F4 is the selector for the beeper On / Off mode.
The beeper is always on when a test routine is finished. To indicate that a running test is finished the beeper
sounds 3 times.
F5 Timer
Pressing of F5 will show the total operating time of the test equipment.
F6 Set voltage
Power On setting of the following parameters:
F1: Vn Nominal supply voltage for the DUT. By selecting Vn in all voltage settings, the voltage in this Set
voltage menu will be taken.
F2: I Maximal current setting for the VDS 200 after power ON.
