Product Labeling
IND100077-202
Label Locations
Number ID and coloring based on “Label Size and Types“ table from previous page. All illustrations below are seen
from rear (and side where needed) with connectors facing down. Actual labels regarding its size and text orientation
vs product size is drawn in. Due to space restrictions on selected units, some labels will be rotated 90 degrees to t
properly. The arrangement of labels may be shifted/stacked differently as it is based on factory options, such as; Touch
Screen and Operating System (OS), but they will be grouped together where possible.
Label Positions Notes Applies for Product Range
Warranty labels covers screw.
Labels placed on rear.
1 on rear chassis
1 on terminal plate
HD 16T30 MMC-xxx-xxxxxx
Warranty labels covers screw.
Labels placed on rear.
1 on rear chassis
1 on terminal plate
HD 21T30 MMC-xxx-xxxxxx
Warranty labels covers screw.
Labels placed on rear.
1 on rear chassis
1 on terminal plate
HD 24T30 MMC-xxx-xxxxxx
Warranty labels covers screw.
Labels placed on rear.
1 on rear chassis
1 on terminal plate
HD 27T30 MMC-xxx-xxxxxx
