General Installation Recommendations
Installation
IND100078-70
Cables
Use only high quality shielded signal cables.
Cable Entries & Connectors (Marked area)
Illustration below for smallest/largest sizes only.
Bottom View Back View
Maximum Cable Length
Any cable should generally be kept as short as possible to provide a high quality input/output. The maximum signal
cable length will depend not only on the signal resolution and frequency, but also on the quality of the signal output from
the computer/radar.
