Unpacking the shipping boxes
You will have received your system either fully assembled and cabled in an EMC cabinet,
or in shipping boxes to be unpacked and installed into your own cabinet.
For damaged or missing components, notify your Sales associate immediately for
replacements.
Procedure
l
If your system was shipped fully assembled and cabled in an EMC cabinet:
a. Follow the unpacking instructions on the outside of the box.
b. Go directly to Cable your system on page 25 of this installation guide to verify
the cabling.
l
If your system was shipped in separate boxes and needs to be assembled in your own
cabinet:
a. Verify that you have received all of the DPE components, including cables, bezel,
rail kit, and mounting screws. Table 2 on page 14 shows the shipping contents.
Table 2 DPE container contents
Disk Processor Enclosure
(DPE)
Front Disk-processor enclosure (Jetfire)
A
B
SP
SP
Will Make the Array Unusable
Caution: Array Software on drives 0-3. Removing or relocating them
01
01
AC
DC
!
1
0
1
0
X4
AC
DC
!
X4
X4
X4
AB
Mounting screws (4)
SAS cables (4)
mini-SAS HD to mini-
SAS connectors
Adjustable rail kit
Rails (2)
Screws (4 per rail)
Unpack your system
14 EMC VNX Series VNX5400 Block Installation Guide
