Figure 3 Installing the DPE rails
R
L
VNX-000369
Installing components
CAUTION
Some of the components are heavy and lifting and attaching them to the rack may
require two people. If needed, use an appropriate lifting device (mechanical lift).
Install the components in the appropriate order.
About the 3U Disk Processor Enclosure (DPE)
The disk processor enclosure is a 3U, 25 2.5" drive DPE.
The front and rear view of the DPE are shown in Figure 4 on page 21.
Assemble components in your cabinet
20 EMC VNX Series VNX5400 Block Installation Guide
