Table 4 3U, 15 3.5" drive DAE
3U, 15 3.5" drive DAE
(1)
SAS SAS SAS SAS SAS
A
B
#
X4
6Gb SAS
#
X4
6Gb SAS
SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS
Mounting screws (4)
Adjustable rail kit
Rails (2)
Screws (4 per rail)
Power cables (2)
Note
Illustrations show standard US power cables.
SAS cables (2)
mini-SAS to mini-
SAS connectors
Add additional storage
Unpacking DAEs 35
