October 2015
Service Instructions
127072E Rev. C
29
Section 5: Module Removal and Installation
Module Removal and Installation
5�7 G2 through G10 Powr Swivl™ Removal
5�7�1 Push the guide block to the side of housing (1-10) that will expose the extension
rod assembly (1-50).
NOTE:
The guide block can be moved by inserting a long non-metallic rod through the hole where
the blind end cap was removed and pushing on the guide block.
5�7�2 Refer to assembly drawing page 2 of 2 Detail "B". Use Bettis tool part number as
listed in chart in Section 1 step 1.5.2 to remove retainer nut assembly (1-60) from
the guide block (1-30).
CAUTION: CAREFULLY HANDLE SPHERICAL WASHERS
When removing rod extension assembly from guide block be careful not to drop one of the
spherical washers inside the housing.
5�7�3 Remove rod extension assembly (1-50) from guide block (1-30).
NOTE:
One spherical washer (1-40) will be removed from guide block (1-30) when extension rod
assembly is removed.
5�7�4 Remove the remaining spherical washer (1-40) from guide block (1-30).
5�8 G2 through G10 Powr Swivl Module Installation
WARNING: CONFIRM OVERTRAVEL POSITION
The actuator must be in the appropriate overtravel position. Conrm overtravel position by
observing if the guide block (1-30) is against the inner wall of housing (1-10).
5�8�1 Push the guide block to the required side of the housing (1-10).
NOTE:
The guide block can be moved by inserting a long rod through either end of the housing
and pushing on the guide block.
5�8�2 Lubricate two spherical washers (1-40) and one extension rod assembly (1-50).
5�8�3 Install one spherical washer (1-40) into the side of guide block (1-30).
