Emerson Bettis G2 Series - M18 Hydraulic Overrides Cylinder Removal

October 2015
Service Instructions
127072E Rev. C
35
Section 6: Actuator Support Information
Actuator Support Information
6�7 G5 Tool Table
Table 15� G5 Tool Style and Wrench Size
ITEM
NO�
WRENCH
SIZE
ITEM
QTY�
LOCATION OR
DESCRIPTION
RECOMMENDED
TOOL STYLE
1-110 3/4” 8 Cover Screws Socket
1-120 3/4” 4 Yoke Cover Screws Socket
1-160 9/16” 6 Hex Cap Screws Socket
1-180 3/4” Sq. 2 Stop Screws Open End or Adjustable
1-190 2-3/8” 2 Heavy Hex Jam Nuts Open End or Adjustable
3-40 1/2” Sq. 1 Piston Rod Male Drive
3-90 15/16” 6 Hex Nuts Socket
3-100 3/4” 4 Hex Cap Screws Socket
3-105 3/4” 4 Standard Hex Nuts Socket
3-115 3/4” 4 Hex Cap Screws Socket
3-120 5/8” Sq. 1 Square Head Pipe Plug Open End or Adjustable
3-210 9/16” Sq. 4 Square Head Pipe Plug Open End or Adjustable
5-20 3/4” 8 Hex Cap Screws Socket
7-80 3/4” 8 Hex Cap Screws Socket
7-110 1/8” Sq. 1 Square Head Pipe Plug Open End or Adjustable
7-120 1/2” Sq. 1 Square Head Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
- 3/4” 1 Pull Rod Male Drive
6�8 G7 Tool Table
Table 16� G7 Tool Style and Wrench Size
ITEM
NO�
WRENCH
SIZE
ITEM
QTY�
LOCATION OR
DESCRIPTION
RECOMMENDED
TOOL STYLE
1-110 3/4” 8 Cover Screws Socket
1-120 3/4” 4 Yoke Cover Screws Socket
1-160 9/16” 8 Hex Cap Screws Socket
1-180 1” 2 Stop Screws Open End or Adjustable
3-40 3/4” Sq. 1 Piston Rod Male Drive
3-90 1-1/2” 6 Hex Nuts Socket
3-100 15/16” 8 Hex Cap Screws Socket
3-105 15/16” 8 Standard Hex Nuts Socket
3-115 15/16” 8 Hex Cap Screws Socket
3-120 15/16” 1 Hex Head Pipe Plug Open End or Adjustable
3-210 9/16” Sq. 4 Square Head Pipe Plug Open End or Adjustable
5-20 15/16” 8 Hex Cap Screws Socket
7-80 15/16” 8 Hex Cap Screws Socket
7-100 15/16” 8 Hex Cap Screws Socket
7-110 9/16” 1 Flush Socket Head Pipe Plug Allen
7-130 9/32” Sq. 1 Square Head Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
- 3/4” 1 Pull Rod Male Drive
