October 2015
Service Instructions
127072E Rev. C
31
Section 6: Actuator Support Information
Actuator Support Information
Section 6: Actuator Support Information
6�1 Module Volume Table
Table 9� M11 Hydraulic Override System Fluid Volume Table
ACTUATOR SIZE G01 G2 G3 G4 G5 G7 G8 G10
APPROX� VOLUME
FLUID FOR M11
SYSTEM
Quarts 1.6 1.8 2.0 3.6 10.2 9.7 15.9 27.0
Liters 1.5 1.7 1.9 3.4 9.6 9.1 15.1 25.6
6�2 Module Weight Tables
Table 10� Module Weights by Item Number and Actuator Housing Size
ITEM
NO�
G01
WT�
G2
WT�
G3
WT�
G4
WT�
G5
WT�
G7
WT�
G8
WT�
G10
WT�
DESCRIPTION
1
Lbs 83 110 162 280 545 1025 1495 2550
Drive Module
Kg 38 50 73 127 247 465 678 1157
1
Lbs 26 N/A N/A N/A N/A N/A N/A N/A
1.5” Dia.
Power Module
Kg 12 N/A N/A N/A N/A N/A N/A N/A
1
Lbs 25 30 N/A N/A N/A N/A N/A N/A
1.7” Dia.
Power Module
Kg 11.4 13.6 N/A N/A N/A N/A N/A N/A
3
Lbs 26 29 43 N/A N/A N/A N/A N/A
2.0” Dia.
Power Module
Kg 11.7 13 19.5 N/A N/A N/A N/A N/A
3
Lbs 27 30 45 N/A N/A N/A N/A N/A
2.2” Dia.
Power Module
Kg 12.2 13.6 20.4 N/A N/A N/A N/A N/A
3
Lbs 28 31 48 71 N/A N/A N/A N/A
2.5” Dia.
Power Module
Kg 12.7 14.1 21.7 32 N/A N/A N/A N/A
3
Lbs 29 35 48 84.5 N/A N/A N/A N/A
3.0” Dia.
Power Module
Kg 13 15.8 21.7 38 N/A N/A N/A N/A
3
Lbs 32 38 52 83 160 N/A N/A N/A
3.5” Dia.
Power Module
Kg 14.5 17.2 23.5 37.6 73 N/A N/A N/A
3
Lbs N/A 42 57 84 170 287 N/A N/A
4.0” Dia.
Power Module
Kg N/A 19 25.8 38 77 130 N/A N/A
3
Lbs N/A N/A 59 86 177.5 301 N/A N/A
4.5” Dia.
Power Module
Kg N/A N/A 26.7 39 80.5 136 N/A N/A
3
Lbs N/A N/A N/A 92 173 317 411 N/A
5.0” Dia.
Power Module
Kg N/A N/A N/A 41.7 78 144 186 N/A
3
Lbs N/A N/A N/A 106 184 303 475 729
6.0” Dia.
Power Module
Kg N/A N/A N/A 49 83 137 215 331
3
Lbs N/A N/A N/A N/A 194 331 485 783
7.0” Dia.
Power Module
Kg N/A N/A N/A N/A 88 150 220 255
3
Lbs N/A N/A N/A N/A 228 337 459 756
8.0” Dia.
Power Module
Kg N/A N/A N/A N/A 103 153 208 343
Table 8 (continued).......
To Next Page
