October 2015
Service Instructions
127072E Rev. C
34
Section 6: Actuator Support Information
Actuator Support Information
6�5 G3 Tool Table
Table 13� G3 Tool Style and Wrench Size
ITEM
NO�
WRENCH
SIZE
ITEM
QTY�
LOCATION OR
DESCRIPTION
RECOMMENDED
TOOL STYLE
1-110 9/16” 8 Cover Screws Socket
1-160 9/16” 4 Yoke Cover Screws Socket
1-180 1/2” Sq. 2 Stop Screws Open End or Adjustable
1-190 1-5/16” 2 Hex Jam Nuts Open End or Adjustable
3-40 3/8” Sq. 1 Piston Rod Male Drive
3-90 3/4” 6 Standard Hex Nuts Socket
3-100 9/16” 4 Hex Cap Screws Socket
3-105 9/16” 4 Standard Hex Nuts Socket
3-115 9/16” 4 Hex Cap Screws Socket
3-120 9/16” Sq. 1 Square Head Pipe Plug Open End or Adjustable
3-210 7/16” Sq. 4 Square Head Pipe Plug Open End or Adjustable
5-20 9/16” 6 Hex Cap Screws Socket
7-80 9/16” 6 Hex Cap Screws Socket
7-110 1/8” Sq. 1 Square Head Pipe Plug Open End or Adjustable
7-120 1/2” Sq. 1 Square Head Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
- 3/8” 1 Pull Rod Male Drive
6�6 G4 Tool Table
Table 14� G4 Tool Style and Wrench Size
ITEM
NO�
WRENCH
SIZE
ITEM
QTY�
LOCATION OR
DESCRIPTION
RECOMMENDED
TOOL STYLE
1-110 9/16” 8 Cover Screws Socket
1-160 9/16” 4 Yoke Cover Screws Socket
1-180 3/4” Sq. 2 Stop Screws Open End or Adjustable
1-190 1-13/16” 2 Hex Jam Nuts Open End or Adjustable
3-40 1/2” Sq. 1 Piston Rod Male Drive
3-90 15/16” 6 Standard Hex Nuts Socket
3-100 3/4” 4 Hex Cap Screws Socket
3-105 3/4” 4 Standard Hex Nuts Socket
3-115 3/4” 4 Hex Cap Screws Socket
3-120 5/8” Sq. 1 Square Head Pipe Plug Open End or Adjustable
3-210 9/16” Sq. 4 Square Head Pipe Plug Open End or Adjustable
5-20 3/4” 6 Hex Cap Screws Socket
7-80 3/4” 6 Hex Cap Screws Socket
7-110 1/8” Sq. 1 Square Head Pipe Plug Open End or Adjustable
7-120 1/2” Sq. 1 Square Head Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
- 3/4” 1 Pull Rod Male Drive
