Emerson Bettis G2 Series Disassembly And Reassembly

October 2015
Service Instructions
127072E Rev. C
36
Section 6: Actuator Support Information
Actuator Support Information
6�9 G8 Tool Table
Table 17� G8 Tool Style and Wrench Size
ITEM
NO�
WRENCH
SIZE
ITEM
QTY�
LOCATION OR
DESCRIPTION
RECOMMENDED
TOOL STYLE
1-110 3/4” 12 Cover Screws Socket
1-120 3/4” 4 Yoke Cover Screws Socket
1-160 9/16” 8 Hex Cap Screws Socket
1-180 1-1/4” 2 Stop Screws Open End or Adjustable
3-40 3/4” Sq. 1 Piston Rod Male Drive
3-90 1-1/2” 8 Hex Nuts Socket
3-100 1-1/8” 8 Hex Cap Screws Socket
3-105 1-1/8” 8 Standard Hex Nuts Socket
3-115 1-1/8” 8 Hex Cap Screws Socket
3-120 15/16” 1 Hex Head Pipe Plug Open End or Adjustable
3-210 9/16” Sq. 4 Square Head Pipe Plug Open End or Adjustable
5-20 1-1/8” 8 Hex Cap Screws Socket
7-80 1-1/8” 8 Hex Cap Screws Socket
7-100 1-1/8” 8 Hex Cap Screws Socket
7-110 9/16” 1 Flush Socket Head Pipe Plug Allen
7-120 9/16” Sq. 2 Square Head Pipe Plug Open End or Adjustable
7-130 9/32” Sq. 1 Square Head Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
- 3/4” 1 Pull Rod Male Drive
6�10 G10 Tool Table
Table 18� G10 Tool Style and Wrench Size
ITEM
NO�
WRENCH
SIZE
ITEM
QTY�
LOCATION OR
DESCRIPTION
RECOMMENDED
TOOL STYLE
1-110 3/4” 16 Cover Screws Socket
1-120 3/4” 4 Yoke Cover Screws Socket
1-160 9/16” 8 Hex Cap Screws Socket
1-180 1-1/2” 2 Stop Screws Open End or Adjustable
3-40 3/4” Sq. 1 Piston Rod Male Drive
3-90 1-7/8” 8 Hex Nuts Socket
3-100 1-5/16” 8 Hex Cap Screws Socket
3-105 1-5/16” 8 Standard Hex Nuts Socket
3-115 1-5/16” 8 Hex Cap Screws Socket
3-120 15/16” 1 Hex Head Pipe Plug Open End or Adjustable
3-210 9/16” Sq. 4 Square Head Pipe Plug Open End or Adjustable
5-20 1-5/16” 8 Hex Cap Screws Socket
7-80 1-5/16” 8 Hex Cap Screws Socket
7-100 1-5/16” 8 Hex Cap Screws Socket
7-110 9/16” 1 Flush Socket Head Pipe Plug Allen
7-130 9/32” Sq. 1 Square Head Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
- 3/4” 1 Pull Rod Male Drive
